B24A

MAIN FEATURE

Wellhead hydraulic crusher mainly operates by the side of wellhead or crush entrance of a mine(incl. black, non-ferrous , and coal mines) , a quarry , a concentration plant , and an ore-pass. It is a more effective way of crushing instead of those old ways such as hammering , reblasting etc.

1.   electricity droved high efficiency and low power consumption. Only need 30% power compared with engine droved ones.
2.   computer simulation tech. designed vibration-damper can reduce the high frequency vibration from the hydraulic crusher head to the core mechanism.
3.   movable chassis can enlarge the working area also reduce the high frequent vibration from the crusher head to the main body of the equipment.
4.    operator cabin equipped with cool/warm air conditioner to provide comfortable work environment.
5.    advanced hydraulic control system using hydraulic control prior devices and compound proportion control devices.




TECHNICAL SEPCIFICATION

Model

B24A

The impact of hydraulic

14~16MPa

Impact frequency

5~8Hz

Impact energy

4500~6000J

Total width

2990mm

Cab height

3010mm

Back-end radius of gyration

2940mm

Minimum ground clearance

460mm

Tension wheel center to wheel center

3465mm

Track plate width

600mm

Maximum working radius

9120mm

Maximum working height

4560mm

The smallest radius of gyration

2500mm

Transport height

3150mm

The total transportation length

10230mm

Maximum flow

158L/min×2

Rated pressure

34.3MPa

Working speed

4.5/3.2km/h

Grade ability

35°

Rotary speed

11rpm

Ground pressure

0.51MPa

Motor power

110 KW

Host weight

18.5T
